CPVC Pipes
Highlights of the Products:
- Ideal for hot and cold water applications
- Suitable for water temperature upto 93oC
- Can withstand 28.1kg/cm2 pressure at 27oC and 6.93kg/cm2 at 82oC
- Wide Range of pipes and fittings from 1⁄2” to 4”
- Safe for potable water
- UV Stabilised
- No bacterial growth
- Ease of installation
- Designed for over 50 years life
- Pipes upto 2” are manufactured as per IS:15778:2007 and fittings as per ASTM standards
Product availability, Pressure rating and Standards
Swipe to left or right to see the full table
| GRADE |
DIAMETER |
STANDARD |
OPERATING PRESSURE KG/CM3 |
| PIPES |
FITTINGS |
270C |
820C |
| SDR11 | 1/2" to 2" | IS:15778:2007 | ASTM D 2846 | 28.1 | 6.93 |
| SDR 13.5 | 1/2" to 2" | IS:15778:2007 | - | 22.23 | 5.61 |
Swipe to left or right to see the full table
| GRADE |
DIAMETER |
STANDARD |
OPERATING PRESSURE KG/CM3 |
| PIPES |
FITTINGS |
270C |
820C |
| SCH40 | 3" | ASTM F 441 | ASTM F 438 | 18.28 | 4.57 |
| SCH40 | 4" | ASTM F 441 | ASTM F 438 | 15.47 | 3.87 |
| SCH80 | 2 1/2" | ASTM F 441 | ASTM F 439 | 29.53 | 7.38 |
| SCH80 | 3" | ASTM F 441 | ASTM F 439 | 26.01 | 6.33 |
| SCH80 | 4" | ASTM F 441 | ASTM F 439 | A22.49 | 5.62 |
CPVC Pipes
Highlights of the Products:
- Ideal for hot and cold water applications
- Safe for potable water
- Environment – friendly
- Wide range of pipes and fittings from 1⁄2” to 4”
- Lead Free
- UV Stabilised
- No bacterial growth
- Ease of installation
- Cost- effective solution
- Pipes manufactured as per ASTM D1785 and fittings as per ASTM D 2466 & 2467
Product availability and Standards
Swipe to left or right to see the full table
| Variants |
sizes available |
pipe |
fittings |
| Schedule 40 |
1/2”-4” |
STMD 1785 |
STM D2466 |
| Schedule 40 |
1/2”-4” |
STMD 1785 |
STM D2466 |
Pressure rating
Swipe to left or right to see the full table
| Pressure Rating - UPVC PIPES SCH40 |
|
| NOMINAL DIA |
AVERAGE OUTER DIAMETER (MM) |
MIN. WALL THICKNESS (MM) |
MAX WORKING PRESSURE(KG/CM2) @ 23C |
BURST PRESSURE |
| INCH |
MM |
(KG/CM2) |
| 1/2 | 5 | 1.34 | .77 | 2.22 | 34.30 |
| 1/4 | 0 | 6.67 | .87 | 3.75 | 08.29 |
| - | 5 | 3.40 | .38 | 1.61 | 01.26 |
| 1/4 | 2 | 2.16 | .56 | 6.00 | 3.00 |
| 1/2 | 0 | 8.26 | .68 | 3.25 | 4.54 |
| - | 0 | 0.32 | .91 | 9.68 | 2.61 |
| 1/2 | 5 | 3.02 | .16 | 1.11 | 8.22 |
| - | 0 | 0.32 | .91 | 9.68 | 2.61 |
| - | 0 | 8.90 | .49 | 8.25 | 9.04 |
| - | 0 | 14.30 | .02 | 5.50 | 9.97 |
